H3C EWP-WA7220X-FIT Best price in Dubai UAE
Supports Wi-Fi 7 with 2×2 MIMO and speeds up to 5.37 Gbps.
Supports 160 MHz channels, 4096-QAM, MLO, and enhanced OFDMA.
Provides 1×2.5GE and 1×10G SFP+ uplinks with redundant connectivity.
Supports PoE+ input through hybrid copper-fiber cable for distances up to 400 metres.
Supports CloudAP, FitAP, and AnchorAP modes with Cloudnet and AD-Campus management.
Features AI-powered dynamic power saving and intelligent RF optimization.
Offers WPA2/WPA3 security, rogue device detection, fast roaming, and wireless fault diagnosis.
H3C EWP-WA7220X-FIT Buy with Best Price from authorized supplier for H3Cproducts in UAE H3C WA7220X – Wi-Fi 7 Dual-Radio High-Performance Access Point Distributor for Africa dsrtech.ae, H3C Dubai
Hardware Specifications
| Weight | 1.336 kg |
| Dimensions (W × D × H) | 240 × 240 × 65 mm (without mounting brackets) |
| Interfaces | 1 × 100/1000M/2.5G RJ-45 Ethernet PoE input; 1 × 1G/10G SFP+ optical PoE input |
| Console Port | 1 × RJ-45 management console port |
| USB Port | 1 × USB 2.0, 2.5W |
| PoE Input | RJ-45 Ethernet and SFP+ optical ports; IEEE 802.3at |
| Local Power Supply | PoE injector (sold separately) |
| Antenna Type | Built-in omnidirectional antenna |
| Antenna Gain | 5GHz: 4.4dBi peak (2.8dBi equivalent); 2.4GHz: 4.6dBi peak (2.9dBi equivalent) |
| Frequency Bands | 2.4GHz: 2.400–2.4835GHz; 5GHz: 5.150–5.850GHz, subject to regulatory domain |
| Modulation Technology | DSSS, OFDM, OFDMA |
| Modulation Modes | 802.11b: BPSK, QPSK, CCK; 802.11a/g/n: BPSK, QPSK, 16/64-QAM; 802.11ac: up to 256-QAM; 802.11ax: up to 1024-QAM; 802.11be: up to 4096-QAM |
| Data Rates | 802.11b: up to 11Mbps; 802.11a/g: up to 54Mbps; 802.11n: up to 600Mbps; 802.11ac: up to 6,933Mbps; 802.11ax: up to 9,608Mbps; 802.11be: up to 23,059Mbps |
| Maximum Transmit Power | 5GHz: 26dBm; 2.4GHz: 30dBm, subject to local regulations |
| Adjustable Power Granularity | 1dBm increments |
| Reset Button | Factory reset and CloudAP/FitAP mode control |
| Security Slot | Kensington security slot |
| Installation | Wall or pole mounting; mounting bracket sold separately |
| LED Indicators | Yellow, green and blue status LEDs |
| Operating Temperature | −40°C to +65°C |
| Storage Temperature | −40°C to +85°C |
| Operating Humidity | 0%–100%, non-condensing |
| Storage Humidity | 0%–100%, non-condensing |
| Protection Class | IP68 |
| Surge Protection | 6kV common-mode |
| Power Consumption | Maximum 25.5W with 802.3at PoE or PoE injector; actual consumption varies with usage |
| Safety Standards | IEC/EN 62368-1, GB 4943.1 |
| EMC Standards | EN 301 489 series, EN 60601-1-2, EN 55032, EN 55035, CISPR 32/35, AS/NZS CISPR 32, ICES-003 Issue 7, GB/T 9254.1/9254.2, GB 17625.1/17625.2, IEC/EN 61000-4 and 61000-3 series |
| Radio Standards | ETSI EN 300 328, EN 301 893, EN 300 440, EN 303 687, FCC Part 15E |
| RoHS Standards | EN IEC 63000:2018 |
| Health Standards | EN 50385:2017, EN IEC 62311:2020 |
| MTBF (25°C) | 1,879,934 hours |
Software Specifications
| Product Type | Outdoor dual-radio Wi-Fi 7 access point supporting IEEE 802.11a/b/g/n/ac/ac Wave 2/ax/be |
| Operating Modes | Fit AP, Cloud AP and Anchor AC; modes can be switched through CLI, wireless controller, H3C intelligent O&M platform or reset button |
| Supported Controllers | H3C WX2800X, WX3800X and WX5800X series |
| Dual-Radio Configuration | 5GHz: 2×2:2, up to 2.882Gbps; 2.4GHz: 2×2:2, up to 0.688Gbps |
| Channel Bandwidth | 5GHz: 20/40/80/160MHz; 2.4GHz: 20/40MHz |
| Maximum Transmission Speed | 3.57Gbps |
| Maximum Clients | 512 clients (256 on 5GHz and 256 on 2.4GHz), environment dependent |
| Maximum BSSIDs | 8 per radio |
| Wi-Fi 7 Features | 4096-QAM, Multi-Link Operation (MLO), preamble puncturing, Multi-RU, uplink/downlink MU-MIMO and OFDMA |
| Wi-Fi 6 Features | Target Wake Time (TWT), BSS coloring, spatial reuse, MU-MIMO and OFDMA |
| WLAN Basics | A-MPDU, A-MSDU, LDPC, LACP, STBC, DFS, TxBF, CCF, MRC and CDD/CSD |
| Tunnel Management | CAPWAP, DTLS encryption, IPv4/IPv6, AC discovery, NAT, time synchronization, dual tunnels, PPPoE client and IPsec in Cloud AP mode |
| WLAN Management | Automatic RF adjustment, SSID hiding, client limits, centralized/local/policy forwarding, VLAN binding, user isolation, load balancing, band steering and 802.11k/v/r roaming |
| WLAN Extensions | Multicast enhancement, RSSI location, Mesh, wireless probing, Hotspot 2.0 and Bonjour gateway |
| User Authentication | 802.1X, MAC, Portal, PSK, Private-PSK/PPSK and social-media authentication in Cloud AP mode |
| EAP Methods | EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, EAP-FAST, GTC and EAP-SIM |
| Wireless Security | WPA2, WPA3, OWE, AES, TKIP, CCMP, WEP40/104, packet and MAC filtering, broadcast suppression, EAD, management frame protection, WIPS and IPSG |
| Layer 2 and Layer 3 | Static/DHCP IP, DHCP server/client/relay, NAT/NAT66/NAT logging, LLDP, STP, IPv4/IPv6 ICMP, ACL, DHCP, TFTP, FTP and DNS |
| Service Assurance | Remote AP, Doctor AP, spectrum analysis, 802.11ax-only access, bandwidth guarantee, port aggregation, broadcast suppression, weak-signal client blocking, roaming optimization and software recovery |
| Quality of Service | WMM, QoS mapping and prioritization, packet filtering, traffic classification, CAR, user bandwidth management, ATF, CAC, SQA and UCC |
| Power Saving | Green AP, U-APSD and SM Power Save |
| Management and Maintenance | Web management via HTTP/HTTPS, SNMP v1/v2c/v3, MIB, SSH v2, Telnet, FTP/TFTP, CLI, Syslog, secure boot and NETCONF |
| IEEE Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax/be, 802.11d/e/h/i/w/u, 802.11k/v/r, 802.3at, 802.3az and 802.15.1 |
| Wi-Fi Certifications | Wi-Fi 7, Wi-Fi 6E, Wi-Fi 6, WMM, WPA, WPA2, WPA3 Enterprise/Personal (SAE) and Enhanced Open (OWE) |
