H3C 9801A89L Best price in Dubai UAE
Supports Wi-Fi 7 with 2×2 MIMO and speeds up to 3.57 Gbps.
Features 160 MHz channels, 4096-QAM, MLO, and enhanced OFDMA.
Provides a 2.5GE uplink, 5G optical port, and five Gigabit Ethernet downlink ports.
Supports CloudAP, FitAP, and AnchorAP modes with Cloudnet and AD-Campus management.
Enhances network performance with intelligent RF optimization, fast roaming, and Doctor AP diagnostics.
Provides WPA2/WPA3 security, WIPS protection, and Secure Boot.
Reduces power consumption with AI-powered dynamic power saving.
H3C 9801A89L Buy with Best Price from authorized supplier for H3Cproducts in UAE H3C WA7320H-HI – Wi-Fi 7 Dual-Radio High-Performance Access Point Distributor for Africa dsrtech.ae, H3C Dubai
Hardware Specifications
| Weight | 315g |
| Dimensions (W × D × H) | 86 × 170 × 40 mm (without mounting brackets) |
| Ethernet Interfaces | 5 × 10/100/1000M RJ-45 downlink ports; 1 × 100/1000M/2.5G RJ-45 uplink port; 1 × 1000M/2.5G/5G SFP uplink port |
| Console Port | 1 × RJ-45 management console port |
| USB Port | 1 × USB 2.0, 2.5W |
| PoE Input | 1 × 100/1000M/2.5G Ethernet, IEEE 802.3at/af |
| PoE Output | 2 × 10/100/1000M Ethernet, IEEE 802.3af; 15W shared output power |
| Local Power Supply | 54V DC adapter, center-positive circular plug (sold separately) |
| Antenna | Built-in antenna |
| Antenna Gain | 6GHz: 5.3dBi; 5GHz: 5.4dBi; 2.4GHz: 3.3dBi |
| IoT Module | BLE 5.3 |
| Frequency Bands | 2.4GHz, 5GHz and 6GHz; available bands depend on the regulatory domain |
| Modulation Technology | DSSS, OFDM and OFDMA |
| Modulation Modes | BPSK, QPSK, CCK, 16QAM, 64QAM, 256QAM, 1024QAM and 4096QAM, depending on Wi-Fi standard |
| Data Rates | 802.11b: up to 11Mbps; 802.11a/g: up to 54Mbps; 802.11n: up to 600Mbps; 802.11ac: up to 6,933Mbps; 802.11ax: up to 9,608Mbps; 802.11be: up to 23,059Mbps |
| Maximum Transmit Power | 23dBm per band (2.4GHz, 5GHz and 6GHz); subject to local regulations |
| Power Adjustment | 1dBm increments |
| Reset Button | Factory reset and CloudAP/FitAP mode control |
| Security Lock | Kensington-compatible Phillips screw |
| Installation | Wall mounting; bracket preinstalled |
| LED Indicators | Yellow, green and blue status LEDs |
| Operating Temperature | 0°C to +40°C |
| Storage Temperature | –40°C to +70°C |
| Humidity | 5%–95%, non-condensing |
| Protection Rating | IP41 |
| Surge Protection | 4KV common-mode |
| Power Consumption | 802.3at: 26.6W or 15.6W depending on radio configuration; 802.3af: 13.1W; DC: 30.6W |
| Safety Standards | IEC/EN 62368-1, GB 4943.1 |
| EMC Standards | EN 301 489 series, EN 60601-1-2, EN 55032/55035, CISPR 32/35, AS/NZS CISPR 32, ICES-003, GB/T 9254.1/.2, GB 17625.1/.2, IEC/EN 61000 series |
| Radio Standards | ETSI EN 300 328, EN 301 893, EN 300 440, EN 303 687, FCC Part 15E |
| RoHS Standards | EN IEC 63000:2018 |
| Health Standards | EN 50385:2017, EN IEC 62311:2020 |
| MTBF (25°C) | 277.962 years |
Software Specifications
| Product Type | Wall-plate dual-radio Wi-Fi 7 access point |
| Wireless Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax/be |
| Operating Modes | Fit AP, Cloud AP and Anchor AC |
| Supported Controllers | H3C WX2800X, WX3800X and WX5800X Series |
| Radio Configuration | Dual-radio operation: 5GHz 2×2:2 up to 2.882Gbps + 2.4GHz 2×2:2 up to 0.688Gbps; alternative 6GHz + 2.4GHz configuration as specified by the source |
| Channel Bandwidth | 6GHz: up to 160MHz; 5GHz: up to 160MHz; 2.4GHz: up to 40MHz |
| Maximum Transmission Speed | Up to 3.57Gbps |
| Maximum Clients | 1,024 clients; actual capacity depends on deployment conditions |
| Maximum BSSIDs | 16 per radio |
| Wi-Fi 7 Features | 4096-QAM, Multi-Link Operation (MLO), preamble puncturing, Multi-RU, MU-MIMO and OFDMA |
| Wi-Fi 6 Features | Target Wake Time (TWT), BSS Coloring, spatial reuse, MU-MIMO and OFDMA |
| WLAN Features | A-MPDU, A-MSDU, LDPC, LACP, STBC, DFS, TxBF, CCF, MRC and CDD/CSD |
| Tunnel Management | CAPWAP, DTLS encryption, IPv4/IPv6, dual tunnels, NAT, PPPoE and IPsec in Cloud AP mode |
| WLAN Management | Automatic RF adjustment, SSID hiding, client limits, centralized/local/policy forwarding, VLAN binding and user isolation |
| Load Balancing and Roaming | Traffic-, user- and band-based load balancing; band steering; 802.11k/v/r roaming |
| Advanced WLAN Features | Multicast enhancement, BLE/RSSI location, IoT gateway, Mesh, wireless probing, Hotspot 2.0 and Bonjour gateway |
| Authentication | 802.1X, MAC, Portal, PSK, PPSK, EAP and supported social login in Cloud AP mode |
| Wireless Security | WPA2, WPA3, OWE, AES, TKIP, WEP, packet/MAC filtering, broadcast suppression, EAD, management frame protection, WIPS and IPSG |
| Layer 2/Layer 3 | Static/DHCP IP, DHCP server/client/relay, NAT/NAT66, LLDP, STP, IPv4/IPv6 ICMP, ACL, TFTP, FTP and DNS |
| Service Assurance | Remote AP, Doctor AP, spectrum analysis, intelligent bandwidth guarantee, port aggregation, broadcast suppression, weak-signal client blocking and software recovery |
| QoS | WMM, traffic prioritization, bandwidth management, Air Time Fairness (ATF), Call Admission Control (CAC), SQA and UCC |
| Power Saving | Green AP, U-APSD and SM Power Save |
| Management and Maintenance | Web GUI, SNMP v1/v2c/v3, MIB, SSH v2, Telnet, FTP/TFTP, CLI, Syslog, secure boot and Netconf |
| IEEE Standards | 802.11a/b/g/n/ac/ac Wave 2/ax/be; 802.11d/e/h/i/w/u/k/v/r; 802.3af/at, 802.3az and 802.15.1 |
| Wi-Fi Certifications | Wi-Fi 7, Wi-Fi 6E, Wi-Fi 6, WMM, WPA, WPA2 and WPA3 Enterprise/Personal, Enhanced Open (OWE) |
