Omada by Tplink SX3832 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots
24x 1/2.5/5/10 Gbps RJ45 ports
8x 1/10 Gbps SFP+ slots
640 Gbps switching capacity
Centralized cloud management via the web or the Omada app†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
ERPS supports rapid protection and recovery in a ring topology
| Feature | Details |
|---|---|
| Interface | 24x 100M/1G/2.5G/5G/10G RJ45 Ports (Auto-Negotiation/MDI/MDIX) 8x 1/10G SFP+ Slots 1x RJ45 Console Port 1x USB Type-C Console Port |
| Fan Quantity | 2 |
| Physical Security Lock | Yes |
| Power Supply | 100–240 V AC ~ 50/60 Hz |
| Dimensions | 17.3 x 8.7 x 1.7 in (440 x 220 x 44 mm) |
| Mounting | Rack Mountable |
| Max Power Consumption | 104.9 W (110V/60Hz) 106.5 W (220V/50Hz) |
| Max Heat Dissipation | 357.81 BTU/hr (110V/60Hz) 363.23 BTU/hr (220V/50Hz) |
| Switching Capacity | 640 Gbps |
| Packet Forwarding Rate | 240 Mpps |
| MAC Address Table | 32K entries |
| Packet Buffer Memory | 24 Mbit |
| Jumbo Frame | 9 KB |
| Quality of Service (QoS) | 8 priority queues 802.1p CoS / DSCP priority SP, WRR, SP+WRR scheduling Port/flow rate limiting QoS remark support |
| L2 & L2+ Features | IPv4/IPv6 interfaces (128) Static routing (48 routes) ARP (static/dynamic), Proxy & Gratuitous ARP DHCP Server & Relay Link aggregation, STP Loopback detection, flow control Port mirroring |
| L2 Multicast | 4000 IGMP groups (IPv4/IPv6) IGMP/MLD snooping Multicast VLAN Registration Multicast filtering profiles |
| Advanced Features | Auto device discovery Batch config & firmware upgrade Network monitoring & alerts Reboot scheduling |
| ISP Features | L2PT, DLDP PPPoE ID insertion ERPS, 802.3ah OAM DDM |
| VLAN | 4K VLAN groups 802.1Q VLAN MAC VLAN (256 entries) Protocol VLAN Private VLAN, GVRP VLAN mapping/replacement Voice VLAN |
| Access Control List (ACL) | Time-based ACL MAC/IP/IPv6 ACL Packet content ACL Policy: mirroring, redirect, rate limit, QoS Applied per port/VLAN |
| Security | IP-MAC-Port binding DHCP Snooping, ARP Inspection IPv4/IPv6 Source Guard DoS protection 802.1X, RADIUS, TACACS+ Port security (64 MAC/port) HTTPS & SSH secure management |
| IPv6 Features | Dual IPv4/IPv6 stack IPv6 routing & ACL ND, ICMPv6, DHCPv6 IPv6 SNMP, SSH, SSL, HTTP/HTTPS |
| MIBs | RFC1213, RFC2233, RFC1643 Bridge & RMON MIBs RADIUS MIBs TP-Link private MIB |
| Management | Web GUI, CLI, SNMP v1/v2c/v3 Omada cloud/controller support Zero-touch provisioning LLDP, diagnostics, system logs |
| Certification | CE, FCC, RoHS |
| Package Contents | SX3832 Switch Power cord Console cable Rackmount kit Rubber feet Installation guide |
| System Requirements | Windows, macOS, Linux, UNIX, NetWare |
| Operating Temperature | -5 C to 50 C |
| Storage Temperature | -40 C to 70 C |
| Operating Humidity | 10–90% RH (non-condensing) |
| Storage Humidity | 5–90% RH (non-condensing) |
