Ubiquiti Enterprise Access Hub - EAH-8
Enterprise-grade access hub with entry and exit control up to eight doors and battery backup support.
| UA-Reader Lite Specifications | |
|---|---|
| General | |
| Dimensions | 94.9 x 40 x 31.1 mm (3.7 x 1.6 x 1.2") |
| NFC Card & Keyfob Access | Yes |
| Mobile Unlock | Yes |
| Handwave Request to Exit | Yes |
| NDAA Compliant | Yes |
| Weatherproofing | IP54 |
| UL 294 Rating | |
| Destructive Attack | Level I |
| Line Security | Level I |
| Endurance | Level I |
| Standby Power | Level I |
| Mechanical | |
| Enclosure Material | Polycarbonate |
| Mounting | Wall-mount, gang box mount (included) |
| Environmental | |
| Indoor / Outdoor Use | Yes |
| Operating Temperature | -20 to 40 C (-4 to 104 F) |
| Operating Humidity | 5 to 90% noncondensing |
| Networking & Connectivity | |
| Networking Interface | (1) 10/100 MbE port |
| Connectivity | BLE 4.1, Ethernet |
| Power | |
| Power Method | PoE |
| Max Power Consumption | 6W |
| Supported Voltage Range | 44–57V DC |
| Power Supply Compliance |
UL 294 Power-limited Class 2 PSU UL 60950-1 / 62368-1 LPS/PS2 PSU |
| Hardware | |
| LEDs | B/W |
| Button | (1) Factory-reset |
| NFC | |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18") |
| NFC Technology |
ISO 14443A, 14443B, 15693 NFC Tag 1, 2, 3, 4, 5 MIFARE Classic, Plus, Ultralight, DESFire |
| PoE Cabling Requirements | |
| Cat 5e minimum recommended. Conductor gauge: 26 AWG (patch cords), 24 AWG (horizontal or riser cable). | |
| Compliance & Certifications | |
| CAN/ULC-60839-11-1 Grade | Grade I |
| Certifications | CE, FCC, IC, Anatel, SRRC, UL 294, CAN/ULC-60839-11-1 |
| Document | UA-Reader Lite, V02 |
| Software | |
| Management Application | Access |
| Software Information | Version available at https://unifi.ui.com |
