Ubiquiti Long-Range Ethernet Repeater - UACC-LRE
Long-range Gigabit Ethernet adapter that receives PoE/PoE+ and offers passthrough PoE output.
Extend PoE connections up to 1 km
(1) GbE RJ45 port for PoE/PoE+ input
(1) GbE RJ45 port for passthrough PoE output
10kA+ surge protection
Works reliably in extreme temperatures (-40 to 80 C)
| Dimensions | |
|---|---|
| Size | 196.5 x 93.5 x 39 mm (7.7 x 3.7 x 1.5") |
| Mechanical | |
| Enclosure Material | UV stabilized polycarbonate |
| Mounting Material | Stainless steel |
| Weatherproofing | IPX5 |
| Hardware | |
| Power Method | PoE/PoE+ 2-pairs (Pins 1, 2+; 3, 6-) |
| Max. Power Consumption | 1.5W (Excluding PoE output) |
| Networking Interface | (2) GbE RJ45 ports |
| PoE Interface | (1) Passthrough PoE output 2-pairs (Pins 1, 2+; 3, 6-) |
| Total Non-Blocking Line Rate | 2 Gbps |
| Switching Capacity | 4 Gbps |
| Forwarding Rate | 1.488 Mpps |
| Total Available PoE | 22.5W |
| Voltage Range (PoE Mode) | 37–57V DC |
| ESD/EMP Protection | Air/contact: ±30kV |
| DC Sparkover Voltage | 90V at 100V/s |
| Max. Impulse Sparkover Voltage | 700V at 1kV/μs |
| Discharge Current | 10kA+ |
| Max. MTU | 1,500 bytes |
| LEDs |
System: Blue (Power ON) Ethernet: Green (1 Gbps), Amber (10/100 Mbps) PoE: Amber (Passthrough PoE Out) |
| Operating Temperature | -40 to 80C (-40 to 176F) |
| Operating Humidity | 10 to 95% non-condensing |
