Ubiquiti USW-Pro-HD-24-UK Best price in Dubai UAE
Professional-grade, Layer 3 Etherlighting switch with (2) 10 GbE, (22) 2.5 GbE, and (4) 10G SFP+ ports.
Ubiquiti USW-Pro-HD-24-UK Buy with Best Price from authorized supplier for Ubiquitiproducts in UAE Ubiquiti Pro HD 24 Layer 3 Etherlighting Switch - USW-Pro-HD-24-UK Distributor for Africa dsrtech.ae, Ubiquiti Dubai
| Device Specifications | |
|---|---|
| Physical | |
| Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
| Form Factor | Rack mount (1U) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400–1200 mm (15.7–47.2") |
| LCM Display | 1.3" touchscreen |
| Ports & Connectivity | |
| 2.5 GbE RJ45 | 22 ports (2.5G/1G/100M/10M) |
| 10 GbE RJ45 | 2 ports (10G/5G/2.5G/1G/100M) |
| 10G SFP+ | 4 ports (10G/1G) |
| Redundancy | DC Power Backup |
| Etherlighting™ | Ethernet ✓, SFP+ ✓ |
| Layer 3 | Yes |
| Performance | |
| Switching Capacity | 230 Gbps |
| Total Non-Blocking Throughput | 115 Gbps |
| Forwarding Rate | 171.12 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 32,000 |
| L3 Table Size – ARP Entries | 12,000 |
| L3 Table Size – IPv4 Routes | 12,000 |
| Packet Buffer Size | 2 MB |
| Access Lists |
IPv4: 128 MAC: 128 |
| Layer 3 Features | |
| DHCP Server (Local Networks) | Yes |
| DHCP Relay | Yes |
| Inter-VLAN Routing (Local Networks) | Yes |
| Static Routing (Local Networks) | Yes |
| Layer 2 Features | |
| LACP Port Aggregation | Yes |
| STP & RSTP | Yes |
| QoS (DSCP) | Yes |
| Pro AV Profiles | Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron |
| Advanced IGMP Configuration | Querier, Fast Leave, Router Port |
| IGMP Snooping | Yes |
| 802.1X Control | Yes |
| MAC-Based ACLs & Device Isolation | Yes |
| DHCP Snooping & Guarding | Yes |
| Egress Rate Limit | Yes |
| Flow Control | Yes |
| Storm Control | Yes |
| Multicast & Broadcast Rate Limiting | Yes |
| MAC Address Blocking | Yes |
| IP-Based ACLs & Network Isolation | Yes |
| MAC-Based Port Restriction | Yes |
| Port Isolation | Yes |
| Port Mirroring | Yes |
| Jumbo Frames | Yes |
| LLDP-MED | Yes |
| Voice VLAN | Yes |
| Loop Protection | Yes |
| Hardware | |
| Max. Power Consumption | 60W |
| Power Method | (1) 100–240V AC, 50/60 Hz (1) USP RPS DC input |
| Power Input Method | AC input |
| Power Supply | AC/DC internal, 60W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet, AR |
| Heat Dissipation | 102 BTU/hr |
| Environmental | |
| Operating Temperature | -5 to 40C (23 to 104F) |
| Operating Humidity | 10 to 90% noncondensing |
| Compliance | |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, Anatel: 03853-25-08356 |
| Software | |
| Application Requirements | UniFi Network version 9.0.114 or later |
