H3C EWP-WA7220-HI-FIT Best price in Dubai UAE

Name: H3C EWP-WA7220-HI-FIT Best price in Dubai UAE
Brand: H3C
SKU: EWP-WA7220-HI-FIT
Availability: InStock
Rating: 4 (1 reviews)

Supports Wi-Fi 7 with 2×2 MIMO and speeds up to 6.453 Gbps.

Features 320 MHz channels, 4096-QAM, MLO, and enhanced OFDMA.

Supports 2.4 GHz, 5 GHz, and 6 GHz frequency bands.

Includes Bluetooth, USB, and PoE-out ports for IoT connectivity.

Supports CloudAP, FitAP, and AnchorAP modes with Cloudnet and AD-Campus management.

Provides AI-powered dynamic power saving and intelligent RF optimization.

Offers WPA2/WPA3 security, rogue device detection, fast roaming, and wireless fault diagnosis.

Enquire on Whatsapp

Description

H3C EWP-WA7220-HI-FIT Buy with Best Price from authorized supplier for H3Cproducts in UAE H3C WA7220-HI – Wi-Fi 7 Dual-Radio High-Performance Access Point Distributor for Africa dsrtech.ae, H3C Dubai

Hardware Specifications

Weight	670 g
Dimensions (W × D × H)	220 × 220 × 40 mm (without mounting brackets)
Ethernet Interfaces	1 × 100/1000M/2.5G RJ-45 PoE input; 1 × 100/1000M/2.5G RJ-45 PoE output
Console Port	1 × RJ-45 management console port
USB Port	1 × USB 2.0, 2.5 W
PoE Input	IEEE 802.3af/at
PoE Output	IEEE 802.3af
Local Power Supply	54 V DC adapter (sold separately)
Antenna Type	Built-in omnidirectional antenna
Antenna Gain	6 GHz: 4.4 dBi; 5 GHz: 4.0 dBi; 2.4 GHz: 3.0 dBi. Equivalent gain: 3.1 dBi, 3.2 dBi and 1.9 dBi, respectively
Built-in IoT Module	Bluetooth Low Energy (BLE) 5.3
Frequency Bands	2.4 GHz: 2.400–2.4835 GHz; 5 GHz: 5.150–5.895 GHz; 6 GHz: 5.925–7.125 GHz, subject to regulatory domain
Modulation Technology	DSSS, OFDM and OFDMA
Modulation Modes	BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM and 4096-QAM
Data Rates	802.11b: up to 11 Mbps; 802.11a/g: up to 54 Mbps; 802.11n: up to 600 Mbps; 802.11ac: up to 6,933 Mbps; 802.11ax: up to 9,608 Mbps; 802.11be: up to 23,059 Mbps
Maximum Transmit Power	6 GHz: 23 dBm; 5 GHz: 23 dBm; 2.4 GHz: 23 dBm
Adjustable Power Granularity	1 dBm increments
Reset Button	Factory reset and Cloud AP/Fit AP mode control
Security Slot	Kensington security slot
Installation	Wall or ceiling mounting; bracket preinstalled
LED Indicators	Yellow, green and blue status LEDs
Operating Temperature	–10°C to +50°C
Storage Temperature	–40°C to +70°C
Humidity	5%–95%, non-condensing
Protection Class	IP41
Surge Protection	4 kV common-mode
Power Consumption	802.3at: 18.9 W; 802.3af: 13.6 W; DC: 33.9 W maximum
Safety Standards	IEC/EN 62368-1, GB 4943.1
EMC Standards	EN 301 489-1/-3/-17, EN 60601-1-2, EN 55032/55035, CISPR 32/35, AS/NZS CISPR32, ICES-003 Issue 7, GB/T 9254.1/9254.2, GB 17625.1/17625.2, IEC/EN 61000-3-2/-3-3 and IEC/EN 61000-4-2/-3/-4/-5/-6/-8/-11
Radio Standards	ETSI EN 300 328, EN 301 893, EN 300 440, EN 303 687, FCC Part 15E
RoHS Standards	EN IEC 63000:2018
Health Standards	EN 50385:2017, EN IEC 62311:2020
MTBF (25°C)	2,379,224 hours

Software Specifications

Product Type	Indoor dual-radio Wi-Fi 7 access point supporting IEEE 802.11a/b/g/n/ac/ac Wave 2/ax/be
Operating Modes	Fit AP, Cloud AP and Anchor AC
Supported Controllers	H3C WX2800X, WX3800X and WX5800X Series Wireless LAN Controllers
Radio Configuration	Default dual-radio: 5 GHz 2×2:2 (2.882 Gbps) + 2.4 GHz 2×2:2 (0.689 Gbps); alternative: 6 GHz 2×2:2 (5.765 Gbps) + 2.4 GHz 2×2:2 (0.689 Gbps)
Channel Bandwidth	6 GHz: up to 320 MHz; 5 GHz: up to 160 MHz; 2.4 GHz: up to 40 MHz
Maximum Transmission Speed	6.453 Gbps (6 GHz + 2.4 GHz); 3.57 Gbps (5 GHz + 2.4 GHz)
Maximum Clients	512 listed; source describes 256 clients across each of the stated band combinations. Confirm the intended total limit before publishing.
Maximum BSSIDs	8 per radio
Wi-Fi 7 Features	320 MHz channels, 4096-QAM, Multi-Link Operation (MLO), preamble puncturing, Multi-RU, uplink/downlink MU-MIMO and OFDMA
Wi-Fi 6 Features	Target Wake Time (TWT), BSS Coloring, spatial reuse, MU-MIMO and OFDMA
WLAN Technologies	A-MPDU, A-MSDU, LDPC, LACP, STBC, DFS, transmit beamforming, cellular coexistence, MRC and CDD/CSD
Tunnel Management	CAPWAP, DTLS encryption, IPv4/IPv6, AC discovery, NAT, time synchronization, dual tunnels, PPPoE client and IPsec in Cloud AP mode
WLAN Management	Automatic RF adjustment, SSID hiding, client limits, centralized/local/policy forwarding, VLAN binding, user isolation, load balancing, band steering and 802.11k/v/r roaming
Additional WLAN Features	Multicast enhancement, BLE/RSSI location, IoT gateway expansion, Mesh, wireless probing, Hotspot 2.0 and Bonjour gateway
User Authentication	802.1X, MAC, Portal, PSK, Private-PSK/PPSK, EAP and social-media authentication in Cloud AP mode
EAP Methods	EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, EAP-FAST, EAP-GTC and EAP-SIM
Wireless Security	WPA2, WPA3, OWE, AES, TKIP, WEP40/104, packet and MAC filtering, broadcast suppression, EAD, management frame protection, WIPS and IPSG
Layer 2/3 Features	Static/DHCP IP configuration, DHCP server/client/relay, NAT/NAT66, NAT logging, LLDP, STP, IPv4/IPv6 ICMP, ACL, TFTP, FTP and DNS
Service Assurance	Remote AP operation, Doctor AP, spectrum analysis, 802.11ax-only access, intelligent bandwidth guarantee, port aggregation, broadcast suppression, weak-signal client blocking, roaming optimization and software recovery
QoS	WMM, QoS prioritization and mapping, packet filtering, traffic classification, committed access rate (CAR), user bandwidth management, Air Time Fairness (ATF), Call Admission Control (CAC), SQA and UCC
Power Saving	Green AP, U-APSD and Spatial Multiplexing Power Save
Management and Maintenance	Web GUI via HTTP/HTTPS, SNMP v1/v2c/v3, MIB, SSH v2, Telnet, FTP/TFTP, CLI, Syslog, secure boot and NETCONF
IEEE Standards	802.11a/b/g/n/ac/ac Wave 2/ax/be, 802.11d/e/h/i/w/u/k/v/r, 802.3af/at/bt, 802.3az and 802.15.1
Wi-Fi Certifications	Wi-Fi 7, Wi-Fi 6E, Wi-Fi 6, WMM, WPA, WPA2, WPA3 Enterprise/Personal (SAE) and Enhanced Open (OWE)
