H3C WX5860X Best price in Dubai UAE
Supports up to 10,240 APs and 102,400 clients with 160 Gbps throughput.
Supports Wi-Fi 6 and Wi-Fi 7 access points.
Provides 2 × 40G SFP+ ports for high-speed connectivity.
Ensures high availability with active-standby switchover and N+1 redundancy.
Enables automatic AP upgrades and software hot patching without service interruption.
Supports WPA2/WPA3 security, WIDS/WIPS, and H3C Secure Boot.
H3C WX5860X Buy with Best Price from authorized supplier for H3Cproducts in UAE H3C WX5860X High-Performance Wireless LAN Controller Distributor for Africa dsrtech.ae, H3C Dubai
| Weight | 22.9 kg (with dual power supplies) |
| Dimensions (W × D × H) | 440 × 660 × 88.1 mm |
| Interface | Supports up to 2 interface cards: 2 × 40G QSFP+ or 8 × 10G SFP+ (mutually exclusive), or 8 × GE Combo |
| Management Interface | 1 × Out-of-Band Management (OOBM) |
| USB Ports | 2 × USB 2.0 |
| Throughput | 80 Gbps / 160 Gbps |
| Power Supply | Removable AC or DC modules; supports 1+1 or 1+3 redundancy; maximum output 650 W per module |
| AC Input | Rated: 100–240 VAC, 50/60 Hz; maximum: 90–264 VAC, 47–63 Hz |
| DC Input | −48 V DC to 60 V DC |
| Power Consumption | 184–502 W |
| Modulation Technology | 802.11b: DSSS; 802.11a/g/n/ac: OFDM; 802.11ax/be: OFDMA |
| Modulation Modes | 802.11b: BPSK, QPSK, CCK; 802.11a/g/n: BPSK, QPSK, 16QAM, 64QAM; 802.11ac: up to 256QAM; 802.11ax: up to 1024QAM; 802.11be: up to 4096QAM |
| Data Rates | 802.11b: 1–11 Mbps; 802.11a/g: 6–54 Mbps; 802.11n: 6.5–600 Mbps; 802.11ac: 6.5–6,933 Mbps; 802.11ax: 7.3–9,608 Mbps; 802.11be: 7.3–23,059 Mbps |
| Reset Button | Restores factory defaults |
| Cooling | Internal fans |
| LED Indicators | Boot loader, system, port, power module, and fault status |
| Operating Temperature | 0°C to +45°C |
| Storage Temperature | −40°C to +70°C |
| Operating Humidity | 5%–95% (non-condensing) |
| Storage Humidity | 5%–95% (non-condensing) |
| Protection Class | IP20 |
| Operating Altitude | Up to 5,000 m |
| Safety Standards | FDA 21 CFR Subchapter J, GB 4943.1, UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC 62368-1, EN 62368-1, AS/NZS 62368-1 |
| EMC Standards | EN 55032, EN 55035, EN IEC 61000-3-2/-3-3, CISPR 32/35, GB/T 9254.1/.2, GB 17626.1/.2, IEC 61000-4-2/-3/-4/-5/-6/-8/-11, ETSI EN 300 386 |
| MTBF (25°C) | 52.4 years |
| MTTR | 1 hour |
