Tenda SG04E 4GE PoE xPON ONU
- Compatibility:Huawei/ZTE/Fiberhome/Nokia and other OLTs
- Highly reliable:Working temperature -20 C to+55 C,6KV ports lightning protection
- Supports POE/POE+(SG04E):Each GE port 30W and the entire machine 60W
- Feature:Internet/POE+
- Interface:4xGE
Hardware Features
Standards
ITU G.984.1, ITU G.984.2, ITU G.984.3, ITU G.984.4
IEEE802.3ah,IEEE 802.3at,IEEE 802.3af
Interface
1xSC/APC or SC/UPC (optional)Port
4x1000Mbps RJ45 LAN Ports
1xDC Power
LED
PON、LOS、LAN、PoE
Button
1xRST Button
Optical Mode
Class B+
Optical Wavelength
Transmit at 1310nm
Receive at 1490nm
Transmission Distance
20km Max
Bandwidth
EPON:Upstream 1.244Gbps Max, Downstream 1.244Gbps Max
GPON:Upstream 1.244Gbps Max, Downstream 2.488Gbps Max
Dimensions (LxWxH);
100x100x26mm
TX Power
0.5-5dBm
RX Power
-28--8dBm
lightning Surge
GE: Differential mode:1KV
Common mode:6KV
External Power Supply
AC Power:Differential mode:4KV
Common mode:4KV
Max PoE output power
complete machine<60w
port<30w
Power Consumption
<65w
Certification
CE, RoHS
Software Features
WAN Connection
Bridge Mode
Business Type
Internet
IP Version
IPv4
Environment
Operating Temperature
-20C - 55C
Storage Temperature
-40C - 70C
Operating Humidity
10% - 95% (Non-condensing)
Storage Humidity
5% - 90% (Non-condensing)
