Tenda TEF1109D 9-Port 10/100M Ethernet Desktop Switch
- Desktop mounting & Wall mounting
- Durable metal casing and exquisite design
- 9 10/100Mbps Auto-Negotiation RJ45 ports
Hardware
Network standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
LED Indicator
1x Power,9x Link/Act
Interfaces
9x10/100 Base-TX Ethernet ports(Auto MDI/MDIX)
Transmission media
Recommended: CAT5/5e UTP or better
Dimensions
140.0mmx66.5mmx25.3mm
Material
Metal
Level of protection
Lightning protection for uplink port: 6KV
Lightning protection for power: N/A
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity
1.8 Gbps
Forwarding rate
1.40Mpps
Buffer
1.25Mb
MAC address table
2 K
Power method
Input: 100 - 240 V AC 50/60 Hz
Output: DC 9 - 12 V
Power consumption
Max:<5W
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support
Environment
Operating temperature: 0C - 45C
Storage temperature: -40C - 70C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing
Certifications
CE, FCC, RoHS
Funtions
VLAN:Port 9 is an uplink port and ports 1 to 8 are isolated from each other.
