Tenda TEG1128P-24-410W 26GE+2SFP Ethernet Switch With 24-Port PoE
- Standard 1U height, rack mounted switch
- Support four modes of Standard, Priority, Extend and VLAN
- Single port output power 30W, maximum output power 370W
- 24×Gigabit PoE+ RJ45 ports,2×Gigabit RJ45 ports,and 2×SFP slots
Hardware
Network standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
IEEE 802.3af
IEEE 802.3at
LED Indicator
Power
Link/Act
PoE MAX
Interfaces
(26) 1GE RJ45 ports
(2) 1GE SFP ports
Transmission media
Recommended: CAT5/5e UTP or better
Fan quantity
1
Dimension
440mm*240mm*44mm
Level of protection
Port: 6 KV
Power：6 KV
Forwarding mode
Store-and-forward
Switch capacity
56Gbps
Packet forwarding rate
41.7Mpps
Buffer
4Mb
MAC address table
8K
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 370W
Power consumption
410W
Input voltage
100-240V AC，50 / 60Hz
Mounting
Rack mounting : support
Desktop mounting: support
Wall mounting: support
Environment
Operating temperature：0C - 45C
Storage temperature：-40C - 70C
Operating humidity：10% - 90%,non-condensing
Storage humidity：5% - 90%,non-condensing
Certification
FCC, CE, RoHS
Software
Funtions
One-key to change network mode:
1.Standard: All ports can communicate with each other. It can be used as a common non-management PoE switch.
2.Priority: Ports 1 to 8 are high-priority ports, which greatly reduce packet loss and congestion when the network is congested.
3.Extend: The maximum transmission distance of the 17-24 ports of the switch can reach 250 meters, and all ports can communicate with each other.
4.VLAN: Ports 1 to 24 cannot communicate with each other, but can communicate with ports 25, 26, SFP1 (27), and SFP2 (28), which can be used to isolate broadcast storms and DHCP conflicts.
