TP-Link Omada ER7212PC 3-in-1 Gigabit VPN Gateway with Omada Management
3-in-1 gateway with 8× PoE+ ports and 110W PoE budget.
Centrally manages up to 24 Omada devices.
Up to 12× Gigabit ports.
Up to 4× WAN Ethernet ports.
Supports IPsec, OpenVPN, L2TP, PPTP, WireGuard, and SSL VPN.
Omada cloud and app management.
| Standards and Protocols | • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE • 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, SNMP |
| Interface | • 2 Gigabit SFP WAN/LAN ports** • 1 Gigabit WAN port • 1 Gigabit LAN/WAN port • 8 Gigabit LAN ports |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) • EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) • EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Fan Quantity | Fanless |
| Button | Reset Button |
| Power Supply | 53.5VDC/2.43A Adapter |
| PoE Budget | 8 ports PoE+ output, 110 W PoE Budget |
| Flash | 32Mbit Nor+8GB eMMC |
| DRAM | 2 GB DDR4 |
| LED | PWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| Dimensions (W × D × H) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Protection | 6kV surge protection |
| Enclosure | Steel |
| Mounting | • Desktop • Wall-mount • Rack-mount (rackmount kit sold separately) |
| Max. Power Consumption | 131 W (110 V/60 Hz) (With 110 W PD connected) |
