Ubiquiti E7 Campus Indoor/Outdoor Access Point - E7-Campus
Enterprise-grade indoor/outdoor access point with 10-stream tri-band WiFi 7 performance, PRISM™ active RF filtering technology, integrated directional antennas, a 10 GbE uplink, and a redundant GbE port for high availability.
| Device Specifications | |
|---|---|
| Physical | |
| Dimensions |
Device: 250 x 250 x 45.5 mm (9.8 x 9.8 x 1.8") Articulating mount: 104 x 149.4 mm (4.1 x 5.9") |
| Mounting | Wall, Pole (mounts included), VESA (optional) |
| Weatherproofing | IPX6, IP67 with waterproof door kit (included) |
| Enclosure Material | UV-stabilized polycarbonate, aluminum alloy |
| Mount Material | Stainless steel, aluminum alloy |
| Wind Loading | 164.75 N at 200 km/h (37 lbf at 125 mph) |
| Pole Mount Diameter | 1–2.5" (25–63.5 mm) |
| Wireless | |
| WiFi Standard | WiFi 7 |
| Spatial Streams | 10 |
| Coverage Area | 465 m² (5,000 ft²) |
| Max. Client Count | 1000+ |
| Uplink | 10 GbE, 1 GbE |
| MIMO |
6 GHz: 4 x 4 (DL/UL MU-MIMO) 5 GHz: 4 x 4 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate |
6 GHz: 11.5 Gbps (BW320) 5 GHz: 8.6 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40) |
| Antenna Gain |
6 GHz: 12 dBi (Directional, 90 x 50) 5 GHz: 12 dBi (Directional, 100 x 55) 2.4 GHz: 9 dBi (Directional, 90 x 80) |
| Antenna Beamwidth |
6 GHz: 90 x 50 5 GHz: 100 x 55 2.4 GHz: 90 x 80 |
| Max. TX Power |
6 GHz: 30 dBm (36 dBm EIRP) 5 GHz: 30 dBm 2.4 GHz: 23 dBm |
| Max. BSSIDs | 8 per radio |
| Operating Frequency |
US/CA 2400–2472 MHz U-NII-1: 5150–5250 MHz U-NII-2A: 5250–5350 MHz U-NII-2C: 5470–5725 MHz U-NII-3: 5725–5850 MHz U-NII-5 & -7: 5925–6425 MHz, 6525–6875 MHz Worldwide 2400–2483.5 MHz 5150–5725 MHz 5925–7125 MHz |
| Supported Data Rates | |
| 802.11be (WiFi 7) | 7.3 Mbps – 11.4 Gbps |
| 802.11ax (WiFi 6) | 7.3 Mbps – 4.8 Gbps |
| 802.11ac (WiFi 5) | 6.5 Mbps – 3.4 Gbps |
| 802.11n | 6.5 Mbps – 600 Mbps |
| Wireless & Network Features | |
| Wireless Meshing | Yes |
| Band Steering | Yes |
| 802.11v/r/k | Yes |
| Zero-Wait DFS | Yes |
| Advanced Radio Management | Yes |
| Real-Time Spectral Analysis | Yes |
| Passpoint (Hotspot 2.0) | Yes |
| Captive Portal |
Custom Branding Voucher Authentication Payment-Based Authentication External Portal Server Password Authentication |
| Guest Network Isolation | Yes |
| Private Pre-Shared Key (PPSK) | Yes |
| WiFi Speed Limiting | Yes |
| Client Device Isolation | Yes |
| WiFi Schedules | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Dynamic RADIUS-assigned VLAN | Yes |
| Hardware | |
| Max. Power Consumption | 44W |
| Power Method | PoE++ |
| Supported Voltage Range | 42.5–57V DC |
| Networking Interface |
(1) 10 GbE RJ45 port (1) 1 GbE RJ45 port |
| PRISM™ RF Filtering | Yes |
| Management | Ethernet |
| LEDs | |
| System | R/G/B |
| Environmental | |
| Operating Temperature | -30 to 60C (-22 to 140F) |
| Operating Humidity | 5 to 95% noncondensing |
| Compliance | |
| NDAA Compliant | Yes |
| Certifications | FCC, IC |
| Software Requirements | |
| UniFi Network | Version 9.0.114 and later |
| Mobile App |
iOS 10.20.0+ Android 10.21.3+ |
