Ubiquiti UniFi Access Hub - UA-Hub
A single-door mechanism that provides complete entry and exit control via connected Access Readers.
| General Specifications | |
|---|---|
| Dimensions | 190 x 126 x 30.5 mm (7.5 x 5 x 1.2 in) |
| Enclosure Material | Plastic enclosure with metal mount plate |
| Mounting | DIN rail |
| Indoor / Outdoor | Indoor only |
| UniFi Application & Compliance | |
| Management Application | UniFi Access |
| Supported Doors | 1 |
| NDAA Compliant | Yes |
| UL 294 Level |
Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Inputs & Outputs | |
| Input Terminals |
REX (request to exit) REN (request to enter) REL (remote release) DPS (door position sensor) |
| Dry Output Relay |
Lock: 30V DC, up to 1A Aux: 30V DC, up to 1A |
| Powered Output Relay |
Lock: 12V DC, up to 1A Aux: 12V DC, up to 0.33A Line: 12V DC, up to 0.33A |
| Power & Networking | |
| Power Method | PoE++ |
| PoE Input | PoE++, 50V DC, 1A |
| PoE Outputs | (3) 50V DC, 30W per port (45W max aggregated) |
| Total Available PoE | 60W |
| Max Power Consumption | 51W |
| Networking Interface | (4) 1 GbE ports |
| Max PoE Wattage per Port | 15.4W |
| Environmental | |
| Operating Temperature | 0 to 40 C (32 to 104 F) |
| Operating Humidity | 5 to 90% non-condensing |
| Other | |
| Buttons | Factory reset (1) |
| Document Reference | UA-Hub, Version 02 |
| Software Info | Software version available at https://unifi.ui.com |
