H3C 9801A6YC Best price in Dubai UAE
Supports Wi-Fi 7 with 2×2 MIMO and speeds up to 8.647 Gbps.
Features 320 MHz channels, 4096-QAM, MLO, and enhanced OFDMA.
Provides 1×2.5GE and 1×10G SFP+ uplinks with redundant connectivity and PoE+ support.
Supports dual 5 GHz operation through flexible 6 GHz radio switching.
Includes Bluetooth, USB, and PoE-out for IoT connectivity.
Supports CloudAP, FitAP, and AnchorAP modes with Cloudnet and AD-Campus management.
Offers WPA2/WPA3 security, intelligent RF optimization, fast roaming, and AI-powered power saving.
H3C 9801A6YC Buy with Best Price from authorized supplier for H3Cproducts in UAE H3C WA7320XE – Wi-Fi 7 Dual-Radio High-Performance Access Point Distributor for Africa dsrtech.ae, H3C Dubai
Hardware Specifications
| Weight | 2.05kg |
| Dimensions (W × D × H) | 260 × 260 × 84 mm (without mounting brackets) |
| Interfaces | 1 × 100/1000M/2.5G RJ-45 Ethernet PoE input; 1 × 1000M/10G SFP+ optical PoE input; 1 × 10/100/1000M RJ-45 Ethernet PoE output |
| Console Port | 1 × RJ-45 management console port |
| USB Port | 1 × USB 2.0, 2.5W |
| PoE Input | RJ-45 and SFP+ ports supporting IEEE 802.3bt/at |
| PoE Output | 1 × 10/100/1000M Ethernet, IEEE 802.3af |
| Power Supply | PoE injector (sold separately) |
| Antenna Type | External antenna; gain depends on the antenna used |
| Built-in IoT Module | BLE 5.3 |
| Frequency Bands | 2.4GHz, 5GHz and 6GHz; available channels depend on the regulatory domain |
| Modulation Technology | DSSS, OFDM and OFDMA |
| Modulation Modes | BPSK, QPSK, CCK, 16QAM, 64QAM, 256QAM, 1024QAM and 4096QAM, depending on Wi-Fi standard |
| Data Rates | 802.11b: up to 11Mbps; 802.11a/g: up to 54Mbps; 802.11n: up to 600Mbps; 802.11ac: up to 6,933Mbps; 802.11ax: up to 9,608Mbps; 802.11be: up to 23,059Mbps |
| Maximum Transmit Power | 6GHz: 27dBm; 5GHz: 27dBm; 2.4GHz: 30dBm, subject to local regulations |
| Power Adjustment | 1dBm increments |
| Reset Button | Factory reset and CloudAP/FitAP mode control |
| Security Slot | Kensington security slot |
| Installation | Wall or pole mounting; mounting bracket sold separately |
| LED Indicators | Yellow, green and blue status LEDs |
| Operating Temperature | –40°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Humidity | 0%–100%, non-condensing |
| Protection Rating | IP68 |
| Surge Protection | 6KV common-mode |
| Power Consumption | 802.3bt: 38.6W; 802.3at: 21.1W; PoE injector: 38.6W |
| Safety Standards | IEC/EN 62368-1, GB 4943.1 |
| EMC Standards | EN 301 489 series, EN 60601-1-2, EN 55032/55035, CISPR 32/35, AS/NZS CISPR 32, ICES-003, GB/T 9254.1/.2, GB 17625.1/.2, IEC/EN 61000 series |
| Radio Standards | ETSI EN 300 328, EN 301 893, EN 300 440, EN 303 687, FCC Part 15E |
| RoHS Standards | EN IEC 63000:2018 |
| Health Standards | EN 50385:2017, EN IEC 62311:2020 |
| MTBF (25°C) | 734,102 hours |
Software Specifications
| Product Type | Outdoor dual-radio Wi-Fi 7 access point |
| Wireless Standards | IEEE 802.11a/b/g/n/ac/ac Wave 2/ax/be |
| Operating Modes | Fit AP, Cloud AP and Anchor AC |
| Supported Controllers | H3C WX2800X, WX3800X and WX5800X Series |
| Radio Configuration | Dual-radio configurations include 5GHz + 2.4GHz, 6GHz + 5GHz, dual 5GHz and 6GHz + 2.4GHz |
| Channel Bandwidth | 6GHz: up to 320MHz; 5GHz: up to 160MHz; 2.4GHz: up to 40MHz |
| Maximum Transmission Speed | Up to 8.647Gbps (6GHz + 5GHz); 6.453Gbps (6GHz + 2.4GHz); 5.764Gbps (dual 5GHz); 3.57Gbps (5GHz + 2.4GHz) |
| Maximum Clients | 1,024; actual capacity depends on the deployment environment |
| Maximum BSSIDs | 16 per radio |
| Wi-Fi 7 Features | 320MHz channels, 4096-QAM, Multi-Link Operation (MLO), preamble puncturing, Multi-RU, MU-MIMO and OFDMA |
| Wi-Fi 6 Features | Target Wake Time (TWT), BSS Coloring, spatial reuse, MU-MIMO and OFDMA |
| WLAN Features | A-MPDU, A-MSDU, LDPC, LACP, STBC, DFS, TxBF, CCF, MRC and CDD/CSD |
| Tunnel Management | CAPWAP, DTLS encryption, IPv4/IPv6, dual tunnels, NAT, PPPoE and IPsec in Cloud AP mode |
| WLAN Management | Automatic RF adjustment, SSID hiding, client limits, centralized/local/policy forwarding, VLAN binding and user isolation |
| Load Balancing and Roaming | Traffic-, user- and band-based load balancing; band steering; 802.11k/v/r roaming |
| Advanced WLAN Features | Multicast enhancement, BLE/RSSI location, IoT gateway, Mesh, wireless probing, Hotspot 2.0 and Bonjour gateway |
| Authentication | 802.1X, MAC, Portal, PSK, PPSK, EAP and supported social login in Cloud AP mode |
| Wireless Security | WPA2, WPA3, OWE, AES, TKIP, WEP, packet/MAC filtering, broadcast suppression, EAD, management frame protection, WIPS and IPSG |
| Layer 2/Layer 3 | Static/DHCP IP, DHCP server/client/relay, NAT/NAT66, LLDP, STP, IPv4/IPv6 ICMP, ACL, TFTP, FTP and DNS |
| Service Assurance | Remote AP, Doctor AP, spectrum analysis, intelligent bandwidth guarantee, port aggregation, broadcast suppression, weak-signal client blocking and software recovery |
| QoS | WMM, traffic prioritization, bandwidth management, Air Time Fairness (ATF), Call Admission Control (CAC), SQA and UCC |
| Power Saving | Green AP, U-APSD and SM Power Save |
| Management and Maintenance | Web GUI, SNMP v1/v2c/v3, MIB, SSH v2, Telnet, FTP/TFTP, CLI, Syslog, secure boot and Netconf |
| IEEE Standards | 802.11a/b/g/n/ac/ac Wave 2/ax/be; 802.11d/e/h/i/w/u/k/v/r; 802.3af/at/bt, 802.3az and 802.15.1 |
| Wi-Fi Certifications | Wi-Fi 7, Wi-Fi 6E, Wi-Fi 6, WMM, WPA, WPA2 and WPA3 Enterprise/Personal, Enhanced Open (OWE) |
