Tenda PoE15F 10/100Mbps PoE Injector
- Plug and Play,no configuration required
- Power supply and data transmission distance up to 100 m
- Two RJ-45 port,support 10/100Mbps link rate
- Power consumption one port up to 15.4W
Hardware
Network standards
IEEE802.3、IEEE802.3u
LED Indicator
Link/Act , PoE Status
Interfaces
1x10/100 Base-TX Ethernet ports(Data/PoE)
1x10/100 Base-TX Ethernet ports(Data)
Transmission media
Recommended: CAT5/5e UTP or better
Dimension
84.5mmx44mmx29.8 mm
Level of protection
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Transmission Rate
100Mbps
PoE budget
Single port: AF: 15.4W
Whole device: 15W
Power consumption
15W
Input voltage
100－240V AC 50/60Hz
48V/0.3A DC（Power Adapter Output）
Mounting
Desktop mounting: support
Environment
Operating Temperature: 0C-45C
Storage Temperature: -40C-70C
Operating Humidity: 10%-90% non-condensing
Storage Humidity: 5%-90% non-condensing
Certification
FCC、CE、RoHS
