Ubiquiti UniFi Door Hub Mini - UA-Hub-Door-Mini
Compact Access Control Hub for a single door.
| General Specifications | |
|---|---|
| Dimensions | 113 x 66 x 27.6 mm (4.4 x 2.6 x 1.1 in) |
| Enclosure Material | Polycarbonate, metal |
| Mounting | DIN-rail (Included) |
| Indoor / Outdoor Use | Indoor only |
| UniFi Application & Compliance | |
| Management Application | UniFi Access |
| Supported Doors | 1 |
| Maximum User Count | 3,000 |
| NDAA Compliant | Yes |
| UL 294 Level |
Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Inputs & Outputs | |
| Input Terminals |
(1) Door exit request (1) Door position |
| Dry Output Relay | 30V DC, 1A |
| Wet Output Relay | 12V DC, 1A |
| Power & Networking | |
| Power Method | PoE++ |
| PoE Interface |
(1) PoE++ input, 50V DC, 1A (2) PoE+ outputs, 50V DC, 30W per port (Max 45W aggregated) |
| Networking Interface | (3) GbE RJ45 ports |
| Max Power Consumption |
19W (without PoE output) 50W (with PoE output) |
| Environmental | |
| Operating Temperature | 0 to 40 C (32 to 104 F) |
| Operating Humidity | 5 to 90% non-condensing |
| Other | |
| LEDs | W / B |
| Buttons |
Factory reset (1) Dry/Wet switch (1) |
| CAN/ULC-60839-11-1 Grade | Grade I |
| Document Reference | UA-Hub-Door-Mini, V01 |
| Software Information | Software version available at https://unifi.ui.com |
