Ubiquiti UniFi Indoor Cable Cat6 CMR - U-Cable-C6-CMR
Category 6 Ethernet cable for high-speed, indoor deployments
Category 6 UTP communications multipurpose cable
Riser (CMR)-rated, fire-resistant jacket
Anti-crosstalk divider
Cable length 305 m
| Product Specifications | |
|---|---|
| Length | 305 m (1,000 ft) |
| Type | Category 6 |
| Flame Rating | CMR |
| Operating Environment | Indoor |
| Box Dimensions | 476 x 306 x 419 mm (18.7 x 12 x 16.5") |
| Cable | |
| Jacket Color | White |
| Jacket Diameter | 5.9 ± 0.2 mm |
| Jacket Material | Flame retardant polyvinyl chloride (FRPVC) |
| Shielding Type | UTP |
| Conductor Type | Solid bare copper |
| Conductor Wire Gauge | 23 AWG |
| Bend Radius (Min.) | 24 mm |
| Twisting |
4 Twisted pairs with color code: Pair 1: white-blue / blue Pair 2: white-orange / orange Pair 3: white-green / green Pair 4: white-brown / brown |
| Anti-Crosstalk Divider | ✓ |
| Ripcord | ✓ |
| Standards | |
| Electrical Transmission |
ANSI/TIA-568.2-D ISO/IEC 11801 (Edition 2.2) IEC 61156-5 (Edition 2.1) |
| Flame Test | UL 1666 (CMR) |
| Material and Construction |
UL 444 CSA 22.2 No.214 EU Directive 2011/65/EU (RoHS2) EU Directive 2006/95/EC (LVD) |
| Environmental | |
| Installation Temperature | 0 to 60C (32 to 140F) |
| Ambient Storage Temperature | -20 to 75C (-4 to 167F) |
| Ambient Operating Temperature | -20 to 60C (-4 to 140F) |
